The very adaptable and most popular battery cyclers/analyzers/testers in the whole battery world.
BTS4000 5V series for cells
Neware BTS4000 5V series battery tester ranges from 1mA up to 3000A, you can use it to test coin cells, pouch cells, cylinder(18650, 26650, 27710, etc) and even paralleled battery modules and packs. For all the BTS4000 testers lower or equal to 30W(5V6A or 10V3A), the accuracy is 0.05%FS. And for all the BTS4000 testers higher than 30W, the accuracy is 0.1%FS.
BTS4000 10V-50V series for modules
BTS4000 10V-50V battery testers for battery modules and packs. Almost all the models can be customized with multi output ranges.
- BTS4000-10v100mA(0.05%FS)
- BTS4000-10V3A(0.05%FS)
- BTS4000-10V10A
- BTS4000-10V50A
- BTS4000-15V3A
- BTS4000-20V20A(8 channels)
- BTS4000-20V200A(2 channels)
- BTS4000-30V30A
- BTS4000-30V100A
- BTS4000-50V10A
- BTS4000-50V60A(2 channels)
- BTS4000-50V100A(1 channel)
Pressure Controlled & Airtight Split Coin Cell
This is a solid-state split-able coin cell set with a PEEK (Optional Silicon Nitride, Si3N4, for heating) sleeve with optional inner diameters (ID) of 10mm, 20mm, and 30mm and outer diameters of 40mm continued temperature up to 300°C. The split cell can be placed in a lab press with pressure up to 150 MPa. It is designed to research the effect of pressure on solid-state battery performance, and it can also be used for easy coin cell assembling without any screw and crimping tools.
Specifications
Device composition:
Transfer fixture, insulation mold with Si3N4 sleeve including heating jacket, a temperature controller, pressure sensor, and digital display meter.
Size:
Die inner diameter: 10mm, 20mm, 30mm
Mold outer diameter: 40 mm
Total height: 85 mm
Temperature Range: up to 300°C
Pressure range: 0 – 5T
Sensitivity 1.0 – 2.0 (± 0.1 mv/v )
Voltage: 220V, AC Single phase
Structure and materials
1. The insulation mold is composed of a 10mm internal diameter pressing rod, a pressing piece, a gasket, a mold bottom, and the sleeve is made of silicon nitride.
2. Pushing rods (top and bottom) are made of stainless steel
3. The sleeve’s inner diameter is available with Ø10 mm, Ø20mm and Ø30mm
2. Easy coin cell assembling without any screw and crimping tools.
3. High working temperatures and pressure applications are available
4. To test a solid-state cell at heating conditions, please select a heatable Si3N4 solid-state cell combination that includes a heating jacket and a temperature control unit.
Transfer device
1. 3 M8 screw rods, 90mm diameter upper cover, pressure plate and base.
2. The external diameter of the device is 90mm, and the total height of the screw rod is
146mm.
Pressure sensor
1. Range: 0-5T.
2. Sensitivity 1.0-2.0 ± 0.1mv/v
3. Working temperature range – 20 -+70 ℃
Digital display meter
1. Digital display KG, range 0-5000KG, (adjustable)
2. Voltage: 220V
Die pressure test
The pressure can reach 300-500 mpa (the inner diameter of the insulation mold
varies with the inner diameter). Press to 1 ton, the pressure is about 125 mpa
instrument adopts advanced mechanical design technology, manufacturing process and microcomputer
control technology. The data acquisition is correct and adopts the latest integrated chip. The display adopts a
blue backlight and high-brightness LCD. The data display is clear, and the current liquid is automatically
identified and the corresponding rotation speed and rotor are selected. This instrument has the characteristics
of high measurement sensitivity, reliable test results, convenient operation, and a beautiful and generous shape. It is
a precision instrument used to measure the absolute viscosity of Newtonian liquids and the apparent relative
viscosity of non-Newtonian liquids. It can be widely used in grease, paint, plastics, drugs, food, coatings, glue
and adhesives. Meter, resin, chemical raw materials and other products.
Repeat error (Newtonian liquid): ±1%
Net weight: 6.8 Kg
Climate Chamber
The climate chamber / constant temperature and humidity test chamber used for testing cells and packs at different temperature conditions, damp heat and to check reliability test at different environmental conditions.
The equipment prohibits:
- Testing or storage of samples of flammable, explosive, and volatile substances
- Testing or storage of corrosive substance samples
- Testing or storage of biological samples
- Testing or storage of samples from strong electromagnetic emission sources
- Testing or storage of radioactive material samples
- Testing or storage of highly toxic substance samples
- Testing or storage of samples that may produce flammable, explosive, volatile, highly toxic, corrosive, and radioactive substances during the testing or storage process
Model: BS-CTH150L
Specifications:
- Volume: 150L
- Inner chamber size: 500mm W x 500mm D x 600mm H
- External dimensions: 1000mm W x1000mm D x1470mm H
- Weight: 160Kg
- Power supply: 220V AC Single Phase, 6kW
Model: BS-CTH1000L
Specifications:
- Volume: 1000L
- Inner chamber size: 1000mm W x 1000mm D x 1000mm H
- External dimensions: 1520mm W x1550mm D x1870mm H
- Weight: 364Kg
- Power supply: 380V, 13.5kW
